Centrifugal Fan (AIR/GAS)

Operating principle: The

MAPRO® centrifugal fans, MCF Series, are made of:

• an intake duct conveying the aspirated gas to   the impeller inlet,   which is coaxial to   the shaft;
• a closed impeller

with axial flow inlet and radial flow exit;

• a toroidal discharge volute with tangential   exit.

The compression of the gas occurs through the increment of kinetic energy given to the gas by the vanes of the impeller and the subsequent conversion of the kinetic energy into static pressure in the discharge volute.

Note: The system can be customized according to client requirements, and competitive pricing is offered.
